7 series · 301 part numbers
Product series search
Search series codes, product names or key specifications.
Try MPX/X2, MOV, NTC, Y1 or AEC-Q200.
61
No match. Try a series code or contact STE.
Product lines and series
9 series · 4,582 part numbers
24 series · 8,419 part numbers
7 series · 3,345 part numbers
15 series · 1,557 part numbers
6 series · 396 part numbers
SMD-MOV
SMD-MOV Surface-Mount Metal-Oxide Varistors
Surface-mount metal-oxide varistors for board-level surge protection in high-density power designs. Case sizes 3225 and 4032, nominal codes 201K–821K. Part-number list on request.
- Nominal code range
- 201K–821K
- Case size
- 3225 / 4032
SMD-PTC
SMD PTC Thermistors for Overcurrent Protection
Surface-mount PTC thermistors for board-level overcurrent protection. Rated voltage 260–500 VAC, resistance 10–5,000 Ω. List of STE part numbers on request.
- Rated voltage
- 260–500 VAC
- Resistance
- 10–5,000 Ω
SMD-NTC (Power)
SMD NTC Inrush Current Limiters
Molded SMD power NTC thermistors for inrush current limiting at the power input. R25 1.5–200 Ω, max. steady-state current 1.0–5.0 A, in 1815, 2522 and 3225 packages.
- R25 range
- 1.5–200 Ω
- Max. steady-state current
- 1.0–5.0 A
SMD Sensing NTC
SMD NTC Thermistors for Temperature Measurement
Glass-coated SMD NTC thermistors for PCB temperature sensing and compensation. Case sizes 0201 to 0805, R25 1 kΩ–1.3 MΩ.
- R25
- 1 kΩ–1.3 MΩ
- B25/50
- 3,380–4,500 K
SMD-X1Y1
SMD-X1Y1 Series Safety Certified SMD Ceramic Capacitors (Class X1/Y1)
Resin-molded SMD ceramic safety capacitors, Class X1/Y1, for EMI suppression. X1 760 VAC, Y1 500 VAC, 10–4,700 pF.
- Safety class
- X1 / Y1 (IEC 60384-14)
- Rated voltage
- X1 760 VAC · Y1 500 VAC
View specifications SMD · SMC-X1Y2
SMC-X1Y2 Series Safety Certified SMD Ceramic Capacitors (Class X1/Y2)
Resin-molded SMD ceramic safety capacitors, Class X1/Y2, for EMI suppression. X1 440 VAC, Y2 300 VAC, 10–4,700 pF.
- Safety class
- X1 / Y2 (IEC 60384-14)
- Rated voltage
- X1 440 VAC · Y2 300 VAC
SMD-DC
SMD-DC Series Medium & High Voltage SMD Ceramic Capacitors
Resin-molded SMD ceramic capacitors for high-voltage DC circuits. Rated 1,000, 2,000 and 3,000 VDC, 10–4,700 pF, in 1815 and 2522 formats.
- Rated voltage
- 1 / 2 / 3 kVDC
- Capacitance
- 10–4,700 pF
CY
CY Series Safety Certified Disc Ceramic Capacitors (Class X1/Y1)
Leaded disc ceramic safety capacitors, Class X1/Y1 to IEC 60384-14. X1 up to 760 VAC, Y1 up to 500 VAC, 100–10,000 pF.
- Safety class
- X1 / Y1 (IEC 60384-14)
- Rated voltage
- X1 760 VAC · Y1 500 VAC · 1,500 VDC (Y5U/Y5V)
View specifications CD
CD Series Safety Certified Disc Ceramic Capacitors (Class X1/Y1)
Leaded disc ceramic safety capacitors, Class X1/Y1, up to 500 VAC, 10–4,700 pF. Y5P/Y5U/Y5V certified to Annex I grade IIIB (85 °C / 85% RH).
- Safety class
- X1 / Y1 (IEC 60384-14)
- Rated voltage
- Up to 500 VAC · 1,500 VDC (Y5P/Y5U/Y5V)
View specifications CE
CE Series Safety Certified Disc Ceramic Capacitors (Class X1/Y2)
Leaded disc ceramic safety capacitors, Class X1/Y2 to IEC 60384-14. X1 up to 440 VAC, Y2 up to 300 VAC, 100–10,000 pF.
- Safety class
- X1 / Y2 (IEC 60384-14)
- Rated voltage
- X1 440 VAC · Y2 300 VAC · 1,500 VDC (Annex H)
View specifications HV / SV
HV/SV Series Medium & High Voltage Disc Ceramic Capacitors
Disc ceramic capacitors for medium- and high-voltage DC circuits. Rated 500 VDC–15 kVDC, 100 pF–100,000 pF.
- Rated voltage
- 500 VDC–15 kVDC
- Capacitance
- 100 pF–100,000 pF
CY-AAEC-Q200
Automotive CY Series Safety Certified Ceramic Capacitors (Class X1/Y1, AEC-Q200)
Automotive radial ceramic safety capacitors, Class X1 760 VAC / Y1 500 VAC, 100–4,700 pF. AEC-Q200 qualified part numbers available.
- Safety class
- X1 760 VAC / Y1 500 VAC (IEC 60384-14)
- Automotive qualification
- AEC-Q200 qualified part numbers available
View specifications CE-AAEC-Q200Datasheet on request
Automotive CE Series Safety Certified Ceramic Capacitors (Class X1/Y2, AEC-Q200)
Automotive radial ceramic safety capacitors, Class X1 440 VAC / Y2 300 VAC, 100–10,000 pF. AEC-Q200 qualified part numbers available.
- Safety class
- X1 440 VAC / Y2 300 VAC (IEC 60384-14)
- Automotive qualification
- AEC-Q200 qualified part numbers available
View specifications MPX/X2
MPX/X2 Series Metallized Polypropylene Film Interference Suppression Capacitors (Class X2)
Boxed metallized polypropylene film capacitors for across-the-line EMI suppression, Class X2. Rated 275–350 VAC, 1 nF–10 µF.
- Safety class
- X2, across-the-line
- Rated voltage
- 275 / 305 / 310 / 330 / 350 VAC
View specifications MPK/X1
MPK/X1 Series Metallized Polypropylene Film Interference Suppression Capacitors (Class X1)
Boxed metallized polypropylene film capacitors for across-the-line EMI suppression, Class X1. Rated 330–530 VAC, 1 nF–1 µF.
- Safety class
- X1, across-the-line
- Rated voltage
- 330 / 440 / 480 / 500 / 530 VAC
View specifications MPY/Y2
MPY/Y2 Series Metallized Polypropylene Film Interference Suppression Capacitors (Class Y2)
Boxed metallized polypropylene film capacitors for line-to-earth EMI suppression, Class Y2. Rated 250–350 VAC, 1 nF–1.2 µF.
- Safety class
- Y2, line-to-earth
- Rated voltage
- 250 / 275 / 300 / 350 VAC
View specifications MPX/X2-THBDatasheet on request
MPX/X2-THB Series Metallized Polypropylene Film Interference Suppression Capacitors (Class X2, THB)
Boxed metallized polypropylene film capacitors for across-the-line EMI suppression in humid environments, Class X2. Rated 275–350 VAC, 1 nF–10 µF.
- Safety class
- X2, across-the-line
- THB test
- 85 °C / 85% RH · 240 VAC · 500 h
View specifications MPK/X1-THBDatasheet on request
MPK/X1-THB Series Metallized Polypropylene Film Interference Suppression Capacitors (Class X1, THB)
Boxed metallized polypropylene film capacitors for across-the-line EMI suppression in humid environments, Class X1. Rated 330–530 VAC, 1 nF–1 µF.
- Safety class
- X1, across-the-line
- THB test
- 85 °C / 85% RH · 240 VAC · 500 h
View specifications MPY/Y2-THBDatasheet on request
MPY/Y2-THB Series Metallized Polypropylene Film Interference Suppression Capacitors (Class Y2, THB)
Boxed metallized polypropylene film capacitors for line-to-earth EMI suppression in humid environments, Class Y2. Rated 250–350 VAC, 1 nF–1.2 µF.
- Safety class
- Y2, line-to-earth
- THB test
- 85 °C / 85% RH · 240 VAC · 500 h
View specifications CBB23B-THB
CBB23B-THB Series Box-Type Metallized Polypropylene Film Capacitors (THB)
Boxed metallized polypropylene film capacitors for high-voltage, high-frequency pulse circuits; moisture-resistant double-85 type (85 °C / 85% RH). 350 / 400 VAC, 2.2 nF–1 µF.
- Humidity type
- 85 °C / 85% RH (double-85)
- Rated voltage
- 350 / 400 VAC
MPB/CBB21B-THBDatasheet on request
MPB/CBB21B-THB Series Box-Type Metallized Polypropylene Film Capacitors (THB)
Boxed metallized polypropylene film capacitors for high-frequency, AC, DC and pulse circuits; moisture-resistant double-85 type (85 °C / 85% RH). 100 / 220 / 275 VAC, 0.01–4.7 µF.
- Humidity type
- 85 °C / 85% RH (double-85)
- Rated voltage
- 100 / 220 / 275 VAC
MC3DDatasheet on request
MC3D Series Metallized Polypropylene DC-Link Film Capacitors
Boxed metallized polypropylene DC-link film capacitors for DC-bus filtering and energy storage in converters. 500–1,200 VDC, 2–180 µF, −40 °C to +105 °C.
- Rated voltage
- 500–1,200 VDC
- Capacitance
- 2–180 µF
MPB/CBB21B
MPB/CBB21B Series Box-Type Metallized Polypropylene Film Capacitors
General-purpose boxed metallized polypropylene film capacitors for DC, AC and pulse circuits. Rated 100–630 VDC, 0.01–10 µF.
- Rated voltage
- 100 / 250 / 400 / 630 VDC
- Capacitance
- 0.01–10 µF
CBB23B
CBB23B Series High-Voltage Box-Type Metallized Polypropylene Film Capacitors
Boxed internal-series metallized polypropylene film capacitors for high-voltage pulse circuits. 400–900 VAC / 1,000–2,000 VDC, 1–100 nF.
- Rated voltage
- 400–900 VAC / 1,000–2,000 VDC
- Capacitance
- 1–100 nF
PPSB/CBB81B
PPSB/CBB81B Series High-Voltage Box-Type Metallized Polypropylene Film Capacitors
High-voltage boxed metallized polypropylene film capacitors. 1,000–2,000 VDC, 0.01–0.047 µF.
- Rated voltage
- 1,000–2,000 VDC
- Capacitance
- 0.01–0.047 µF
MMKP82/CBB82B
MMKP82/CBB82B Series Double-Sided Metallized Polypropylene Film Capacitors (Box-Type)
Boxed double-sided metallized polypropylene film capacitors for high-voltage, high-frequency pulse circuits. 400–900 VAC / 1,000–2,000 VDC, 1–100 nF.
- Rated voltage
- 400–900 VAC / 1,000–2,000 VDC
- Capacitance
- 1–100 nF
PPN/CBB13
PPN/CBB13 Series Non-Inductive Polypropylene Film Capacitors
Epoxy-dipped non-inductive polypropylene film/foil capacitors for high-pulse DC and electronic-ballast circuits. 400–1,000 VDC, 1–47 nF.
- Rated voltage
- 400 / 630 / 1,000 VDC
- Capacitance
- 1–47 nF
MPP/CBB21
MPP/CBB21 Series Metallized Polypropylene Film Capacitors
General-purpose epoxy-dipped metallized polypropylene film capacitors for DC, AC, high-frequency and pulse circuits. 100–630 VDC, 0.01–3.3 µF.
- Rated voltage
- 100 / 250 / 400 / 630 VDC
- Capacitance
- 0.01–3.3 µF
CBB23
CBB23 Series Dipped Metallized Polypropylene Film Capacitors
High-voltage dipped metallized polypropylene film capacitors. 1,000–1,600 VDC, 0.001–1.0 µF.
- Rated voltage
- 1,000–1,600 VDC
- Capacitance
- 0.001–1.0 µF
PPS/CBB81
PPS/CBB81 Series High-Voltage Metallized Polypropylene Film Capacitors
Epoxy-dipped high-voltage film capacitors with metallized polypropylene film and aluminum foil, for pulse and resonant circuits. 1,000–2,000 VDC, 1–33 nF.
- Rated voltage
- 1,000 / 1,250 / 1,600 / 2,000 VDC
- Capacitance
- 1–33 nF
MEB/CL21B
MEB/CL21B Series Box-Type Metallized Polyester Film Capacitors
Boxed metallized polyester (PET) film capacitors for general-purpose DC circuits up to +125 °C. 100–630 VDC, 10 nF–2.2 µF.
- Rated voltage
- 100 / 250 / 400 / 630 VDC
- Capacitance
- 10 nF–2.2 µF
MEMB/CL23
MEMB/CL23 Series Miniature Metallized Polyester Film Capacitors
Miniature boxed metallized polyester (PET) film capacitors with 5 mm lead spacing for space-constrained DC circuits. 63–630 VDC, 1 nF–1 µF.
- Rated voltage
- 63 / 100 / 250 / 400 / 630 VDC
- Capacitance
- 1 nF–1 µF
MEF/CL21
MEF/CL21 Series Metallized Polyester Film Capacitors
General-purpose epoxy-dipped metallized polyester (PET) film capacitors for bypass, blocking, coupling and filtering. 100–630 VDC, 10 nF–10 µF.
- Rated voltage
- 100 / 250 / 400 / 630 VDC
- Capacitance
- 10 nF–10 µF
MEF/CL21XDatasheet on request
MEF/CL21X Series Compact Metallized Polyester Film Capacitors
Compact epoxy-dipped metallized polyester (PET) film capacitors for bypass, coupling, filtering and low-pulse circuits. 50–100 VDC, 1 nF–1 µF.
- Rated voltage
- 50 / 63 / 100 VDC
- Capacitance
- 1 nF–1 µF
MPX/X2-AAEC-Q200Datasheet on request
Automotive MPX/X2 Series Metallized Polypropylene Film Interference Suppression Capacitors (Class X2, AEC-Q200)
Automotive boxed metallized polypropylene film capacitors, Class X2, for across-the-line EMI suppression. AEC-Q200 Rev E qualified part numbers available; 275–350 VAC; 1 nF–10 µF.
- Safety class
- X2, across-the-line
- Automotive qualification
- AEC-Q200 Rev E qualified part numbers available
View specifications MPK/X1-AAEC-Q200Datasheet on request
Automotive MPK/X1 Series Metallized Polypropylene Film Interference Suppression Capacitors (Class X1, AEC-Q200)
Automotive boxed metallized polypropylene film capacitors, Class X1, for across-the-line EMI suppression. AEC-Q200 Rev E qualified part numbers available; 330–530 VAC; 1 nF–1 µF.
- Safety class
- X1, across-the-line
- Automotive qualification
- AEC-Q200 Rev E qualified part numbers available
View specifications MPY/Y2-AAEC-Q200Datasheet on request
Automotive MPY/Y2 Series Metallized Polypropylene Film Interference Suppression Capacitors (Class Y2, AEC-Q200)
Automotive boxed metallized polypropylene film capacitors, Class Y2, for line-to-earth EMI suppression. 250–350 VAC; 1 nF–1.2 µF; AEC-Q200 Rev E qualified part numbers available.
- Safety class
- Y2, line-to-earth
- Automotive qualification
- AEC-Q200 Rev E qualified part numbers available
View specifications S
S Series Standard Radial-Leaded Metal-Oxide Varistors
Radial-leaded zinc-oxide disc varistors, 05D–20D, for board-level transient suppression; varistor voltage 18–1,100 V, max. peak current 6,500 A (8/20 µs).
- Nominal varistor voltage
- 18–1,100 V
- Max. peak current (8/20 µs)
- 100–6,500 A
View specifications Z
Z Series High-Energy Radial-Leaded Metal-Oxide Varistors
High-energy radial-leaded zinc-oxide disc varistors, 05D–25D; varistor voltage 18–1,200 V, max. peak current 18 kA (8/20 µs), max. energy 750 J (10/1000 µs).
- Nominal varistor voltage
- 18–1,200 V
- Max. peak current (8/20 µs)
- 250–18,000 A
QDatasheet on request
Q Series 6kV/3kA Radial-Leaded Metal-Oxide Varistors
Surge-type radial-leaded zinc-oxide varistors designated 6 kV / 3 kA, 10D–20D; varistor voltage 82–1,100 V, max. peak current 10 kA (8/20 µs).
- Nominal varistor voltage
- 82–1,100 V
- Max. peak current (8/20 µs)
- 3,500–10,000 A
D
D Series Large-Disc High-Energy Metal-Oxide Varistors
Large-disc high-energy metal-oxide varistors for surge protection in industrial and renewable-energy equipment. V1mA 200–1,800 V, disc size 32–53 mm.
- Nominal varistor voltage V1mA
- 200–1,800 V
- Disc size
- 32–53 mm
R
R Series High-Energy Metal-Oxide Varistors
High-energy metal-oxide varistors in medium and large disc sizes. V1mA 200–1,800 V, disc size 10–34 mm.
- Nominal varistor voltage V1mA
- 200–1,800 V
- Disc size
- 10–34 mm
Q-AAEC-Q200
Automotive Q Series 6kV/3kA Radial-Leaded Metal-Oxide Varistors (AEC-Q200)
Radial-leaded zinc-oxide varistors, 10D–20D, for automotive electronics, with AEC-Q200 qualified part numbers available; varistor voltage 82–1,000 V, max. peak current 10 kA (8/20 µs).
- Automotive qualification
- AEC-Q200 qualified part numbers available
- Nominal varistor voltage
- 82–1,000 V
View specifications NTC-PS
PS Series NTC Inrush Current Limiters
Silicone-coated radial power NTC thermistors for inrush current limiting. R25 0.7–400 Ω, max. steady-state current up to 12 A, operating temperature up to +200 °C depending on disc size.
- Resistance R25
- 0.7–400 Ω
- Max. steady-state current (25 °C)
- 0.1–12 A
View specifications NTC-PP
PP Series NTC Inrush Current Limiters
Phenolic-coated radial power NTC thermistors for inrush current limiting. R25 2.5–200 Ω, max. steady-state current up to 5 A, operating temperature up to +155 °C.
- Resistance R25
- 2.5–200 Ω
- Max. steady-state current (25 °C)
- 0.2–5.0 A
MF51 Special
MF51 Special NTC Temperature Sensors for Electronic Thermometers
MF51 NTC thermistors for temperature sensing in electronic clinical thermometers. Resistance 0.2–1,000 kΩ, B25/50 3,270–4,500 K.
- Resistance
- 0.2–1,000 kΩ
- B25/50 range
- 3,270–4,500 K
MF51
MF51 Series Glass-Encapsulated NTC Thermistors
Glass-encapsulated leaded NTC thermistors for temperature measurement from −20 °C to +250 °C. Three sizes with 1.2–2.0 mm body diameter; thermal time constant 2–11 s in static air.
- Operating temperature
- −20 °C to +250 °C
- Thermal time constant, static air
- 2–11 s
MF52Datasheet on request
MF52 Series Bead-Type Precision NTC Temperature Sensors
Leaded bead NTC thermistors for precision temperature measurement; R25 10–100 kΩ, B25/50 3,380 or 3,950 K, thermal time constant ≤7 s in static air.
- R25
- 10 / 50 / 100 kΩ
- B25/50
- 3,380 K / 3,950 K
MF58
MF58 Series Glass-Encapsulated NTC Thermistors (Diode Type)
Axial glass-encapsulated NTC thermistors for temperature sensing and compensation. Operating temperature −55 °C to +250 °C, R25 0.1 kΩ–3.78 MΩ.
- R25
- 0.1 kΩ–3.78 MΩ
- Operating temperature
- −55 °C to +250 °C
MF59
MF59 Series Glass-Encapsulated Chip NTC Thermistors
Leadless glass-encapsulated NTC thermistors for temperature sensing and compensation. Two body sizes, R25 0.1–100 kΩ, operating temperature −55 °C to +220 °C.
- R25
- 0.1–100 kΩ
- Operating temperature
- −55 °C to +220 °C
CWF
CWF Series Precision NTC Temperature Sensors
Configurable NTC temperature-sensor assemblies with probe, ring-terminal, pipe and overmolded constructions; R25 0.1 kΩ–1 MΩ, B25/50 3,100–4,500 K.
- R25
- 0.1 kΩ–1 MΩ
- B25/50
- 3,100–4,500 K (11 families)
MF11
MF11 Series NTC Thermistors for Temperature Compensation
Radial dipped NTC thermistors for circuit temperature compensation and general temperature measurement. R25 5 Ω–500 kΩ, B25/50 2,600–4,750 K, operating temperature −30 °C to +125 °C.
- R25
- 5 Ω–500 kΩ
- B25/50
- 2,600–4,750 K
MZ11
MZ11 Series PTC Thermistors for Overload Protection
Disc PTC thermistors for overload protection in AC circuits. Rated voltage 65–330 VAC, resistance 1–500 Ω, disc size Φ6–Φ24. List of STE part numbers on request.
- Rated voltage
- 65–330 VAC
- Resistance
- 1–500 Ω
MZ13
MZ13 Series PTC Thermistors for Overcurrent Protection
Disc PTC thermistors for overcurrent protection in high-voltage AC circuits. Rated voltage 260–700 VAC, resistance 10–1,000 Ω. List of STE part numbers on request.
- Rated voltage
- 260–700 VAC
- Resistance
- 10–1,000 Ω
MZB
MZB Series PTC Thermistors for Overload Protection
Disc PTC thermistors for overload protection in AC circuits. Rated voltage 65–330 VAC, resistance 8–500 Ω, disc size Φ6–Φ22. List of STE part numbers on request.
- Rated voltage
- 65–330 VAC
- Resistance
- 8–500 Ω
